Crack test bench, Uniflux UF AL
Specification
- Workpiece length: max. 1000 [mm]
- Main connection: 3x400[V]
- Compressed air: 5 [bar]
- Clamping force: cca. 950 [N]
Description
Crack test bench, Uniflux UF AL – for magnetic particle testing according to EN ISO 9934 with automatic function sequence. Aluminium model.
Features
The crack detection bench UF is equipped with two alternating current magnetisation circuits.
Possible magnetisation methods
- Current flooding: Indication of longitudinal cracks
- Yoke magnetisation: Indication of transverse cracks
Version
- Constant current control with effective value display
- Current flow control in both magnetising circuits
- Electronic demagnetisation in both magnetising circuits
- Automatic function sequence
Modification for combined testing possible. Other clamping methods and modifications on request.
